產品簡介
用於水下的倍力器
諾霸與石油和天然氣行業密切合作，研製出適用於最惡劣環境（如船舶甲板，石油鑽井平台和煉油廠）的扭力儀器和傳感器。
諾霸使用各種耐腐蝕材料，高規格連接器和密封技術，這意味著he系列產品可以在這樣最惡劣環境中使用，而不會損害其性能或壽命。
儘管最初設計是為了滿足石油和天然氣行業的需求，但是在潮濕或塵土飛揚的環境中，無論是戶外必要的應用，還是扭力測量，諾霸的he系列產品是用戶理想的選擇。
用於水下的倍力器
用於水下的倍力器 - 功能介紹
諾霸與石油和天然氣行業密切合作，研製出適用於最惡劣環境（如船舶甲板，石油鑽井平台和煉油廠）的扭力儀器和傳感器。
functions:-
ht5 5:1 for sub sea intervention tools:-
- precision epicyclical gear design for high efficiency in a small, lightweight package
- supplied specifically for use in pressure compensated oil filled sub sea intervention tools with oil filling/drain holes and no grease
- input and output drives can be provided to customer requirements
- manufactured from standard norbar components for trusted reliability and availability of spares
ht5 5:1 with integrated transducer:-
- designed to allow integration into the smallest housing possible to reduce weight and size of complete intervention tool
- transducer is integral part of the gearbox annulus and is made from stainless steel
- torque signal output available in mv/v, 4 to 20ma as 2 or 4 wire versions
- supplied with fully traceable bi-directional torque calibration certificate
about norbar, world leaders in torque equipment
cutting edge - norbar’s state-of-the-art factory facilities ensure we provide the very latest design, manufacturing and quality control technology to achieve the highest level of innovation and precision in the field of torque control equipment.
family values - descendants of the founder, bill brodey, still participate in the business and the company remains every bit as passionate about providing customers with the highest quality products and services as bill was when manufacturing that first torque wrench.
globally available - norbar is the only torque equipment manufacturer to be able to offer torque tool and instrument calibration services to the original factory standard on four continents.
stringent standards - the nata accredited laboratory in adelaide, south australia, nvlap 200596-0 accredited laboratory in willoughby, usa, sac-singlas laboratory in singapore and the laboratory in shanghai accredited by taf and cnas all use the same equipment and procedures as the factory's ukas accredited laboratory, so you are assured that you will always receive the same high standard of service that are norbar’s hallmark.
用於水下的倍力器 - 產品規格
水下乾預式工具中一體式倍力器
| 型號 | 料號 |
| 用於水下乾預式工具的ht5 5:1 | 77331 |
| 用於水下花鍵輸出的ht5 5:1 | 77301 |
以上傳感器的精度為±2%。
帶有一體式傳感器的倍力器
| 型號 | 料號 |
| ht5 5:1帶有一體式傳感器 350 – 3500 n•m | 77141.ind |
